description Electro-Voice ND86 Overview
The Electro Voice ND86 is a handheld dynamic microphone designed for live vocal performance on large and acoustically demanding stages. Its supercardioid pickup pattern emphasizes sound from directly in front while limiting pickup from nearby monitors, instruments, and other performers. Electro Voice specifies a frequency response of 70 Hz to 17 kHz, with response shaping intended to support vocal clarity and projection through a sound reinforcement system.
help Electro-Voice ND86 FAQ
Where should stage monitors be placed when using an Electro-Voice ND86?
Because the ND86 has a supercardioid pattern, its strongest rejection is angled away from the exact rear of the microphone. Wedge monitors are normally placed toward those off-axis rejection zones rather than directly behind the mic.
Does the Electro-Voice ND86 need phantom power?
No. It is a passive dynamic microphone that connects through a standard three-pin XLR cable.
What is the frequency response of the ND86?
Electro-Voice specifies a close-miked response of approximately 30 Hz to 17 kHz. At greater vocal distance, its published response begins around 70 Hz.
How does the ND86 differ from the Electro-Voice ND76?
The ND86 is supercardioid, while the ND76 uses a cardioid pickup pattern. The ND86 therefore offers tighter stage isolation, but it also requires more careful monitor and microphone positioning.
