description Mastech MS8688B Overview
The Mastech MS8688B is a high-quality multimeter designed for both professional and DIY users. It offers AC and DC voltage, current, and resistance measurements with a 400V range. It includes features like continuity testing, diode testing, and a backlight for low-light environments. This multimeter is known for its durability and accuracy in various electrical applications.
info Mastech MS8688B Specifications
| Weight | 280g with battery |
| Display | 4000 count LCD with backlight |
| Data Hold | Yes |
| Dimensions | 158 x 76 x 32mm |
| Diode Test | Yes |
| Power Source | 9V battery |
| Safety Rating | CAT III 600V / CAT II 1000V |
| Auto Power Off | Yes |
| Continuity Test | Yes, with buzzer |
| Ac Current Range | 400µA - 10A |
| Ac Voltage Range | 4V - 400V (600V max) |
| Dc Current Range | 400µA - 10A |
| Dc Voltage Range | 400mV - 400V (600V max) |
| Resistance Range | 400 - 40M |
balance Mastech MS8688B Pros & Cons
- Auto-ranging simplifies operation for both beginners and professionals
- Large LCD display with backlight for easy reading in low-light conditions
- Continuity and diode testing capabilities for comprehensive circuit analysis
- 400V measurement range covers most residential and commercial applications
- CAT III 600V safety rating provides protection during industrial use
- Data hold function freezes readings for convenient recording
- Not a True RMS meter, affecting accuracy on non-sinusoidal waveforms
- Lacks frequency and temperature measurement functions
- Limited current ranges may require additional equipment for high-current applications
- No PC connectivity or data logging capabilities
- Build quality not as robust as premium multimeter brands
help Mastech MS8688B FAQ
Is the Mastech MS8688B True RMS?
No, the MS8688B is not a True RMS multimeter. It uses average responding measurement, which may not accurately read non-sinusoidal waveforms commonly found in variable frequency drives or switching power supplies.
What is the maximum voltage the MS8688B can measure?
The MS8688B can measure DC and AC voltages up to 400V in the primary ranges. It has a 600V rating for higher voltage applications, making it suitable for most residential and light commercial electrical work.
Does this multimeter measure temperature?
No, the MS8688B does not include a temperature measurement function. For temperature readings, you would need to purchase a separate thermometer or upgrade to a multimeter model with K-type thermocouple input.
What safety rating does the MS8688B have?
The MS8688B carries a CAT III 600V safety rating, meaning it's designed for testing in building wiring and fixed industrial installations, providing adequate protection against voltage transients in those environments.
Can I use the MS8688B for automotive diagnostics?
Yes, for basic automotive diagnostics including battery voltage, wiring continuity, and diode testing. However, it lacks temperature measurement and may have limited range for some high-current automotive testing applications.
What is Mastech MS8688B?
How good is Mastech MS8688B?
What are the best alternatives to Mastech MS8688B?
What is Mastech MS8688B best for?
Home hobbyists, DIY enthusiasts, and entry-level technicians seeking a reliable, feature-rich multimeter for general electrical troubleshooting and basic measurements.
How does Mastech MS8688B compare to Fluke 117 Multimeter?
Is Mastech MS8688B worth it in 2026?
What are the key specifications of Mastech MS8688B?
- Weight: 280g with battery
- Display: 4000 count LCD with backlight
- Data Hold: Yes
- Dimensions: 158 x 76 x 32mm
- Diode Test: Yes
- Power Source: 9V battery
